Unit type: terminal unit Frequency band: V band Type and frequency range: 57-66 GHz, TDD/TDMA TDD allocation: dynamic Channel width: 4 x 2160 MHz wide, non-overlapping Modulation: adaptive in 10 levels Output power: up to 13 dBm Range: - Interfaces: 1 x RJ-45 1/2.5/5 GbE with PoE-in, 1 x RJ-45 1 GbE with PoE-out (65 W), 1 x 10 GbE SFP+ Encryption: AES 128-bit Antenna Gain: 36 dBi - 0.16 m (0.5 ft), 42 dBi - 0.31 m (1 ft), 48 dBi - 0.65 m (2 ft) Polarization: linear 3dB Beamwidth: - Power: PoE or 48 VDC, 25 W without PoE-out, 90 W with PoE-out PoE out: port 1: 65 W Operating temperature: -45 °C to 55 °C IP protection: IP67 Product Specification
