Frequency band: 403 - 473 MHz Tuning range: 70 MHz Channel spacing: 12.5, 20, 25 kHz Communication mode: half-duplex Receiver sensitivity: -115 dBm @12.5 kHz, -113 dBm @25 kHz Maximum output power: 0,1...1 W Interface: Ethernet, Bluetooth, USB Connectors: M8-ETH, M8-USB, M8-power Data speed of radio interface: 9600 bps @12.5 kHz, 19200 bps @25 kHz (4FSK, FEC OFF) Operating voltage: 7 – 27.5 VDC Power consumption: TX: 5.5 W @1W, RX: 1.5 W Dimensions: 146 x 67 x 29 mm Weight: 350 g Operating temperature: -20 °C - 55 °C Antenna connector: TNC female Display: yes NMS function: yes IP rating: IP67 Product Specification
